Responsive even with moderate (>200k points) datasets.Relatively short load times / time to first plot.The following highlights a few interesting features of InspectDR: Documentation is a bit limited at the moment.
SMITH CHART SVG HOW TO
Users are encouraged to open an issue if it is unclear how to utilize a particular layer.
Plot application layer: Most end users will likely display/interact with plots/data using the built-in Julia/ GTK+ multi-plot application. Plot widget layer: Library users can also integrate plots to their own GTK+ application by instantiating a single InspectDR widget. Plot image layer: Implemented with the Cairo library, the plot image layer allows the user to render (multi-) plots as simple images. The InspectDR library is implemented using 3 distinct plot layers: Motivation: Despite their great quality, most of Julia's current plotting options were found to be either too slow, and/or provide inadequate interactivity for the author's needs. In design applications, InspectDR allows for efficient, interactive data exploration, thus shortening each iteration of the design cycle. InspectDR is a fast plotting tool with a responsive GUI, targeting quick navigation of simulation results.
Note: In instances where higher-level APIs have limited control over the plot, it is typically possible to tweak the final apearance of the "rendered" ::InspectDR.Plot object using the InspectDR API.
CMDimCircuits.jl: Extends CMDimData.jl with circuit-specific functionnality (ex: signal processing, network analysis. CMDimData.jl: Facilitates parametric analysis with continous f(x) interpolation & multi-dimensional plots. Plots.jl: Succinct plotting interface ideal for interactive exploration (supports multiple backends). Alternative APIs supporting InspectDR include: It will most likely be easier to generate InspectDR plots by leveraging higher-level APIs (unless you have stringent requirements on time-to-first-plot or number of dependencies).
SMITH CHART SVG CODE
Code used to generate more complex plots can therefore be a bit difficult to read/maintain. The InspectDR programming interface is not particularly refined. sample/ / 🎨 SignalProcessing module / 🎨 Plots.jl package
